Utilized in various applications, leaf chains are regulated by ANSI. They can be utilized for lift truck masts, as balancers between counterweight and heads in several machine devices, and for low-speed pulling and tension linkage. Leaf chains are occasionally also referred to as Balance Chains.
Features and Construction
Leaf chains are actually steel chains using a simple link plate and pin construction. The chain number refers to the pitch and the lacing of the links. The chains have particular features such as high tensile strength for each section area, that allows the design of smaller mechanisms. There are B- and A+ kind chains in this particular series and both the AL6 and BL6 Series include the same pitch as RS60. Finally, these chains cannot be driven with sprockets.
Handling and Selection
In roller chains, the link plates have a higher fatigue resistance due to the compressive tension of press fits, yet the leaf chain only has two outer press fit plates. On the leaf chain, the most permissible tension is low and the tensile strength is high. While handling leaf chains it is important to consult the manufacturer's catalogue so as to ensure the safety factor is outlined and utilize safety measures always. It is a better idea to exercise extreme caution and use extra safety measures in functions where the consequences of chain failure are serious.
Utilizing a lot more plates in the lacing results in the higher tensile strength. Because this does not improve the maximum permissible tension directly, the number of plates utilized may be restricted. The chains need frequent lubrication in view of the fact that the pins link directly on the plates, producing a very high bearing pressure. Making use of a SAE 30 or 40 machine oil is frequently advised for the majority of applications. If the chain is cycled over one thousand times in a day or if the chain speed is over 30m for every minute, it will wear extremely rapidly, even with constant lubrication. Therefore, in either of these situations using RS Roller Chains will be a lot more suitable.
The AL-type of chains should only be used under particular conditions like for instance when wear is really not a big concern, if there are no shock loads, the number of cycles does not exceed one hundred a day. The BL-type will be better suited under various conditions.
If a chain with a lower safety factor is selected then the stress load in parts would become higher. If chains are utilized with corrosive elements, then they may become fatigued and break quite easily. Doing regular maintenance is really vital when operating under these types of conditions.
The type of end link of the chain, whether it is an inner link or outer link, determines the shape of the clevis. Clevis connectors or otherwise called Clevis pins are constructed by manufacturers but usually, the user supplies the clevis. A wrongly made clevis can decrease the working life of the chain. The strands must be finished to length by the maker. Check the ANSI standard or contact the manufacturer.
